ROSS - Cross Flow Double Valve with Pressure Switch รุ่น 3573D8630

ROSS – Cross Flow Double Valve with Pressure Switch รุ่น 3573D8630

  • Designed to enable users to comply with current safety regulations.
  • Can be integrated with external monitoring systems to provide for lockout and inhibiting further machine operation until the controls system is reset.
  • Default to de-energized position upon fault condition.
Send Email LINE OA
Categories: , ,

Double Valves with Pressure Switches, Ports 3/8 to 1-1/2

Clutch/Brake Control Function The Crossflows double valve is designed to provide control of clutch/brake mechanisms on stamping presses, and many other critical applications such as alternative lockout systems for energy isolation, air cylinder press load-holding systems, as well as other Category -3 and -4 safety circuits.

DOWNLOAD CATALOG (ดาวน์โหลดแคตตาล็อก)

รุ่น 3573D8630

Details

Port Size (Exhaust) Built in Silencer
Port Thread NPT
Voltage 24 VDC
Mounting Type In-line
Inlet Side Left Side
Status Indicator Pressure Switch
Monitor Type Externally Monitored
Override Without Override
Reset Type N/A
Input to Main Solenoid Independent
Switches for External Monitoring Pressure Switches Included
Solenoid Connection DIN
Status Indicator Connection N/A
Port Size (In) 1-1/2″
Port Size (Out) 1-1/2″
Cv (Exhaust) 43
Cv (In-Out) 21
